Track lighting Architectural WHITE T-bar live end power feed connector 3-wire H-style single circuit

# TLSK137-AWH
Track lighting architectural white t-bar live end power feed connector is an essential track fitting and track connector for supplying power from a junction box or power outlet to the track lighting system when installed on t-bar drop ceilings.

Designer's Note

This fitting is used when you have a drop-T-bar ceiling. It works because there is a offset knock-out 1/2" on the back to allow flex to enter the connector from above. This way you do not have to cut the T-bar to bring power to the track. (like other connectors) On this page (below) you will see a T-Bar clip that allows the track to be easily connected to the support T-bar. Consider how how you are going to connect the power track to the T-bar ceiling This connector may be enough, however in some cities you may be required to have a seismic support. Get with your electrician on this to insure you have all the parts required for the project.

Availability: Typically ships same or next business day!

$14.28

Here to Help

Quality lighting can increase sales, security and property value. Contact us here and we will show you how. Your success is our success.
Also enjoy our video guides and how to's here
Details
The T-bar Live End Track Lighting Connector is used to provide power through the end of the track. This simple connector is used on drop ceilings where there is no junction box to cover. It is large enough that power can come around the t-bar with five knockouts in the back (four on the corners and one in the center) for versatility in bringing power into the connector. Always check local codes before proceeding with any electrical installation.
Additional Information
Color Architectural Matte White
Track Type 3-Wire
Track Style H-Style
Cross Reference Number ET137-WH
Compatible with: Cooper, Glomar, Halo, Hampton Bay
Application Track Lighting System Fitting
Circuits Single
Material Plastic, Steel
Voltage Type Line Voltage (120Volt)
Height (H) 1-1/16"
Width (W) 4-1/4"
Length (L) 4-1/4"
