Track Lighting Suspension Electrical 18 Gauge

Track Lighting Suspension Electrical 18 Gauge

Use the technical drawing to add the needed components for your track lighting suspension system below.

Before you start, always Login or Create an Account to save your shopping cart.

Track Lighting Suspension System #18 Electrical Technical Diagram

Lighting suspension junction box bracket bar and 1" stud

1 Review(s) | Add Your Review

# BB-1/4-20-HD-STUD

$2.90 As low as: $1.85
Black 5" Canopy cover with 5/8" #18 gauge wire power feed access hole for our lighting suspension system

# 5-IN-CAN-COVER-2-18-BK

$3.15
White 5" Canopy cover with 5/8" multi-conductor #18 gauge wire power feed access hole for our lighting suspension system

# 5-IN-CAN-COVER-2-18-WH

$3.15
Black Strain Relief Bushing for multi-conductor #18 gauge wire in our suspension system

# SR-18-BK

$0.65
White Strain Relief Bushing for multi-conductor #18 gauge wire in our track suspension system

# SR-18-WH

$0.65
Lighting Suspension 18/3 SJTOW Black Power Cable 10AMPs 300volt by the foot up to 500ft

# 18/3-SJTOW-Black-105c

$1.25
Lighting Suspension 18/3 SJTOW White Power Cable 10AMPs 300volt by the foot up to 500ft

1 Review(s) | Add Your Review

# 18/3-SJTOW-White-105c

$1.25
18/5-B-SJT Lighting Suspension black power wire for control and power of suspended lighting fixtures

# 18/5-B-SJT

$1.68
18/5-W-SJT Lighting Suspension white power wire for control and power of suspended lighting fixtures

# 18/5-W-SJT

$1.68
Black strain relief with locknut for multi-conductor #18 to #14 gauge wire in our lighting suspension system

# TLSK-Strain-Relief-LockNut-BK

$2.75
Gray strain relief with lock nut for multi-conductor #18 to #14 gauge wire in our lighting suspension system

# TLSK-Strain-Relief-LockNut-GY

$2.75
Lighting Suspension System Ceiling Coupler

1 Review(s) | Add Your Review

# CC-1/4-20

$1.80 As low as: $1.08
Suspension cable for lighting fixtures 24", 1/16 inch diameter

2 Review(s) | Add Your Review

# C-1/16-24-GALV

$1.25 As low as: $0.67
Suspension cable for lighting fixtures 48", 1/16 inch diameter

1 Review(s) | Add Your Review

# C-1/16-50-GALV

$1.98 As low as: $1.06
Suspension cable for lighting fixtures 96", 1/16 inch diameter

# C-1/16-96-GALV

$2.60 As low as: $1.39
Suspension cable for lighting fixtures 150", 1/16 inch diameter

# C-1/16-150-GALV

$3.90
Suspension cable for lighting fixtures 200", 1/16 inch diameter

# C-1/16-200-GALV

$3.90
Suspension cable for lighting fixtures 246", 1/16 inch diameter

# C-1/16-246-GALV

$4.82 As low as: $1.92
Suspension cable for lighting fixtures 300", 1/16 inch diameter

# C-1/16-300-GALV

$5.75
Track Lighting Suspension Cable Glider and Screw

6 Review(s) | Add Your Review

# MGR-SE-8/32-3/8

$3.73 As low as: $2.98
Suspended Track Lighting Cable Cutter

# TL-CUTTER-AS

$29.50
