Track lighting satin L Connector 3-wire H-style power feed single circuit

# TLSK108-SN

Be the first to review this product

Track lighting satin L connector an ideal track fitting and track connector for connecting two power tracks together where a 90° turn is required in a track lighting system. May functions as a power feed.

Designer's Note

NOTES on the Internal Jumpers. In the "More Views" section on this page are photos showing the "jumpers" or short wires that connect one side of the connector to the other. This allows electricity to flow from one track to the other side. If they are removed you will electrically isolate the two tracks. This may be what you need for your specific custom installation , or maybe not.

In the additional photos you will see where we brought in power into the connector to allow the L connector to also be a power feed. Adding these three wires makes the connector space for wiring very tight. We like to use spade lugs to accomplish this, but your electrican may go another direction. The reason we did use the spade lugs is that the wire in this specific application  (suspended track system) is stranded. The jumpers were removed, the feed wires were attached, then the jumpers were put back in. This was done as this L connector was feeding two track runs that terminated at their specific ends. This is not the case if you were doing a square run or rectangle. In these cases the jumpers are not needed as the power is running around the square and although the "power feed" L connector is attached mechanically it is not needed to be connected electrically .

Additionally for your information we included the back side of the L connector where we show a strain relief. This is only used in a suspended track system and not on a ceiling or TBar ceiling install. All of the power feeds are very tight to wire and we strongly recommend that whenever possible that the wire is made up in the connector first, then the wire or flex is then attached to the junction box. You will always have more room in the junction box then you will in the track power feeds.

You never want to install power to the connectors while standing on a ladder, it is a pain to do so.

And the power must be turned off.

We always recommend a licenced experienced electrican.

Availability: Typically ships in 2 business days!

$11.64

Here to Help

Quality lighting can increase sales, security and property value. Contact us here and we will show you how. Your success is our success.
Also enjoy our video guides and how to's here
Details
The "L" connector joins two tracks together in a 90-degree angle that reassembles the shape of a "L". In addition, the "L" connector is equipped with a 1/2" knockout on the back for use as a power feed. Located within the "L" connector are power "jumpers" that can be removed to isolate circuits while maintaining the mechanical track lighting connection.
Additional Information
Color Satin
Track Type 3-Wire
Track Style H-Style
Cross Reference Number HT-275S, STK743, TA106, L904
Compatible with: Cooper, Glomar, Halo, Hampton Bay
Application Track Lighting System Fitting
Circuits Single
Max Watts 200
Voltage Type Line Voltage (120Volt)
Dimensions H x W x L (in) See Spec Sheet
